METALLURGY
Equipment
2 – (5) Ton vertical channel electric induction furnaces providing a daily pour of 20 – 25 tons.
1 – Gas fired pre-heater capable of heating 1,000 lbs. to 1,000 degrees every 10 minutes.
D&E Tight Ladle ductile transfer ladles w/ weights calculated using load cells.
Lab / Analysis
Spectro MaxX LMF06 optical emission spectrometer for on-site chemical analysis
Datacast DC 3000 quicklab for carbon equivalent determination
(2) Heraeus Qube T-2 wireless pyrometers with extra-large temperature display intended to be visible throughout the melt department
(3) King brinell hardness testers
Microscope for Microstructure analysis
Physical analysis provided promptly by a certified outside lab as required by our customers
Casting Weight Range
Ounces to 400 pounds
Materials Cast
- Class 25
- Class 30
- Class 35
- Class 40
- Specialty grades available upon request
- 60-40-18 (as cast or annealed)
- 65-45-12
- 80-55-06
- 80-60-03
- 100-70-03
- 120-90-02
- 110-70-11
- 130-90-09
- 150-110-07
- 175-125-04
- 200-155-02
- 230-185-01
